ArgoX HDSW3 HDMI Switcher 3×1

ArgoX HDSW3 HDMI Switcher 3×1

The 3-port HDMI Switch allows 3 HDMI ports to be switched to a single display using the remote control or buttons on the unit. The unit can also be placed on the end of a long cable to regenerate the signal.

Features:

• Support 2.25Gbps data rate for TMDS clock up to 225MHz
• Support HDMI1.4a
• Support 3D
• Supports highest video resolution 1080p/60Hz
• Support UXGA,WUXGA
• Support 8/10/12 bit deep color
• Support AWG26 HDMI standard cable, Input up to 10 Meters ,output up to 10 Meters
• Supports single high definition display for multiple sources, such as DVD Players and Satellite Receivers, Digital Projectors, A/V Receivers, Set Top Boxes
• Remote Control for operational flexibility and easy to control
• DC5V/1A power supply

Specifications:

• Brand: ArgoX
• Model(s): HDSW3
• HDMI Version: HDMI 1.4A
• HDMI Resolution: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• Support Video Color Format: 8/10/12 bit deep color
• Support Audio Format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
• Max Bandwidth: 225MHz
• Max Baud Rate: 2.25Gbps
• Input Cable Distance: ≤10m AWG26 HDMI standard cable
• Output Cable Distance: ≤10m AWG26 HDMI standard cable
• Max Working Current: 500mA
• Power Adapter Format Input: AC (50Hz, 60Hz) 100V-240V; Output: DC5V/1A
• Operating Temperature Range: (-15℃ to +55℃)
• Operating Humidity Range: 5 to 90%RH (No Condensation)
• Dimension (L x W x H): 128x53x20 (mm)
• Weight: 140g
