Boxxline QB-5 Speaker (SET)

Boxxline QB-5 Speaker (Boxed set of 2)

Ultra-compact, full range, two way passive cabinet for background sound reinforcement.
It consists of a 5” transducer and a 1” high frequency neodymium tweeter. It off ers 90ºconic dispersion and 110 dB SPL (160W program).

Components : LF: 1 x 5″ transducer / HF 1 x 1″ tweeter
Frequency Range : 65 Hz – 20 KHz (-10dB)
Frequency Response : 75 Hz – 18 KHz (± 3dB)
Max SPL : 107 dB – 113 dB peak
Sensitivity : 88 dB (1w @ 1m)
Coverage angle : 90º H x 90º V conic
RMS power : 80 W
Program Power : 160 W
Crossover : 4700 Hz
Impedance : 16 Ω
Material : 9 mm premium birch plywood
Finish : Water based paint
Dimensions : 254 x 167 x 186 mm (H x W x D)
Weight : 3 Kg (6.6 lbs)
