Jedia JPA-240CP Power Amplifier

Jedia JPA-240CP Power Amplifier

A rack mountable 100 volt line power amplifier featuring 240W power output that is designed for installations where further power is required beyond that of a standard mixer amplifier.
XLR or DIN rail connections allow for simple interconnects from the mixer amplifier. Built-in full protection circuits permit safe, trouble-free operation.

Features :

• Automatic variable speed fan
• Over current protection and thermal cut-out
• Output short circuit protection
• Low pass and high pass filter
• 400Hz filter to improve speech clarity
• High efficiency toroidal power and output transformer
• XLR input and link connection with optional screw terminals
• Structure enables air circulation from front to back for more effective cooling
• Quiet power up circuit
• Soft start on power up
• AC or 24V dc operation

Specifications :

Input Sensitivity/Impedance : +4dBu (1.23V)/30kΩ balanced
Rated Output (RMS) : 240W
Output Impedance : 25V, 70V, 100V & 8Ω
THD (1kHz) : <1% (1kHz)
Frequency Response : 35Hz-20kHz
S/N Ratio : >100dB
Input Filter : 400Hz/-3dB
Power Consumption : 650W
Weight : 12.5kg
Power Requirement : 120V/220-240Vac 50/60Hz, 24Vdc
