Martin Audio Wavefront W8LMi Line Array Top Cabinet

Martin Audio Wavefront W8LMi Line Array, price per piece. (Installation Line Array)

The Martin Audio W8LM is a mini line array enclosure designed to bring line array performance benefits to a variety of small and medium scale applications. It meets the need for a versatile, scalable system that can be flown or ground stacked for corporate events, theatres and indoor venues. It is also suitable as a delay system for large scale outdoor sound reinforcement.

Features :

• Mini three-way line array element
• Hybrid® dual 8″ (200mm) LF+MF configuration (-3dB@60Hz)
• LF+MF – 100dB @1W, 1m (single cabinet)
• Twin 1″ (25mm) HF horn – 106dB @1W, 1m (single cabinet)
• Consistent 100º (-6dB) horizontal mid and HF pattern control
• Passive or biamp operation
• 12 ohm system impedance, up to 4 cabinets on one amplifier channel
• Fast, integral rigging system with variable splay angles
• ViewPoint™ array optimisation software
• Factory controller presets for a wide variety of configurations
• Compatible with W8L Longbow and W8LC line-array elements
• Compatible with WSXa, WLX, WMX and WS218X subwoofers

Specifications :

• Type : Three-way, active/passive, mini line array element
• Frequency response : 60Hz-18kHz ± 3dB
• Drivers :
  • 8″ (200mm)/2″ (50mm) voice coil, reflex-loaded direct radiator
  • 8″ (200mm)/2″ (50mm) voice coil, neodymium driver, front horn loaded, rear reflex loaded
  • HF Section 2 x 1″ (25mm) exit HF compression drivers, horn loaded
• Rated power :
  • LF + MF : 400W AES, 1600W peak
  • HF : 75W AES, 300W peak
  • Passive : 400W AES, 1600W peak
• Sensitivity :
  • LF + MF : 100dB
  • HF : 106dB
  • FR : 99dB rising to 105dB at HF
• Maximum SPL :
  • LF + MF : 126dB continuous, 132dB peak
  • HF : 125dB continuous, 131dB peak
  • Passive : 125dB continuous, 131dB peak
• Nominal impedance :
  • LF + MF : 12 ohms
  • HF : 12 ohms
  • FR : 12 ohms
• Dispersion (-6dB) :
  • 100º horizontal (down to 800Hz)
  • 7.5º vertical
  • 120º horizontal (down to 700Hz) @ -10dB
• Crossover : 300Hz passive, 2.2kHz active or passive
• Enclosure : Vertical trapezoid with 3.75º wall angle, multi- laminate birch ply construction
• Finish : Textured black paint
• Protective grille : Black perforated steel
• Connectors : 2 x Neutrik NL4
• Dimensions :
  • (W) 620mm x (H) 243mm x (D) 400mm
  • (W) 24.4ins x (H) 9.6ins x (D) 15.8ins
  • Weight : 29kg (64lbs)
